Descripción
8″,200/400w,98dB,87Hz,90-?5000Hz,50mm,Copper, 8 ohm
Specifications
Nominal diameter: 200 mm (8.0 in)
Nominal impedance 8 O
Minimum impedance 7.2 O
Nominal power handling * 200 W
Continuous power handling * 400 W
Sensitivity (1W/1m) * 98.0 dB
Frequency range 90 5000 Hz
Voice coil diameter 50 mm (2.0 in)
Winding material Copper
Former material Kapton
Winding depth 9 mm (0.37 in)
Magnetic gap depth 8 mm (0.31 in)
Flux density 1.25 T
Design
Surround shape Triple Roll
Cone shape Radial
Magnet material Ferrite
Spider Single
Pole design Straight Pole
Woofer cone treatment None
Parameters *
Fs 87 Hz
Re 5.6 O
Qes 0.2
Qms 3.8
Qts 0.19
Vas 13.0 dm3 (0.46 ft3)
Sd 220.0 cm2 (34.1 in2)
?0 4.1 %
Xmax 3.5 mm
Xvar 4.5 mm
Mms 18 g
Bl 16.6 Txm
Le 0.5 mH
EBP 435 Hz
Mounting And Shipping Info
Overall diameter 225 mm (8.86 in)
Bolt circle diameter 210 mm (8.27 in)
Baffle cutout diameter 187.0 mm (7.36 in)
Depth 91 mm (3.58 in)
Flange and gasket thickness 11 mm (0.43 in)
Air volume occupied by driver 1.2 dm3 (0.04 ft3)
Net weight 4.2 kg (9.26 lb)
Shipping units 1
Shipping weight 4.6 kg (10.14 lb)
Shipping box 260x260x160 mm (10.24×10.24×6.30 in)
Service Kit
RCK008PE218
Marca: BYC
Codigo: 3001445
