Descripción
6.5″,150/300w,96.5dB,140Hz,150-?6000Hz,44mm,Aluminum, 8 ohm
Specifications
Nominal diameter 170 mm (6.5 in)
Nominal impedance 8 O
Minimum impedance 6.5 O
Nominal power handling * 150 W
Continuous power handling * 300 W
Sensitivity (1W/1m) * 96.5 dB
Frequency range 150 6000 Hz
Voice coil diameter 44 mm (1.7 in)
Winding material Aluminium
Former material Glass Fibre
Winding depth 10 mm (0.37 in)
Magnetic gap depth 6 mm (0.25 in)
Flux density 1.45 T
Design
Surround shape Triple Roll
Cone shape Exponential
Magnet material Neodymium Ring
Spider Single
Pole design T-Pole
Woofer cone treatment WP Waterproof Front Side
Parameters *
Fs 140 Hz
Re 5.4 O
Qes 0.46
Qms 2.8
Qts 0.4
Vas 2.7 dm3 (0.09 ft3)
Sd 132.0 cm2 (20.5 in2)
?0 1.6 %
Xmax 2.5 mm
Xvar 3.0 mm
Mms 11 g
Bl 11.0 Txm
Le 0.47 mH
EBP 304 Hz
Mounting And Shipping Info
Overall diameter 187 mm (7.4 in)
Bolt circle diameter 172 mm (6.7 in)
Baffle cutout diameter 145.0 mm (5.7 in)
Depth 73 mm (2.9 in)
Flange and gasket thickness 11 mm (0.4 in)
Air volume occupied by driver 0.6 dm3 (0.02 ft3)
Net weight 1.0 kg (1.2 lb)
Shipping units 1
Shipping weight 1.25 kg (2.75 lb)
Shipping box 221x214x130 mm (8.7×8.4×5.1 in)
Service Kit
RCK06MDN448
Marca: BYC
Codigo: 3009317
