Descripción
15″,400/800w,98.5dB,42Hz,40-?3000Hz,76mm,Copper, 8 ohm
Specifications
Nominal diameter 380 mm (15.0 in)
Nominal impedance 8 O
Minimum impedance 6.3 O
Nominal power handling * 400 W
Continuous power handling * 800 W
Sensitivity (1W/1m) * 98.5 dB
Frequency range 40 3000 Hz
Voice coil diameter 76 mm (3.0 in)
Winding material Copper
Former material Glass Fibre
Winding depth 19 mm (0.75 in)
Magnetic gap depth 11 mm (0.43 in)
Flux density 1.15 T
Design
Surround shape Triple Roll
Cone shape Exponential
Magnet material Neodymium Inside Slug
Spider Single
Pole design Straight Pole
Woofer cone treatment WP Waterproof Front Side
Recommended enclosure 100.0 dm3 (3.53 ft3)
Recommended tuning 47 Hz
Parameters *
Fs 42 Hz
Re 5.1 O
Qes 0.34
Qms 7.9
Qts 0.33
Vas 135.0 dm3 (4.8 ft3)
Sd 855.0 cm2 (132.5 in2)
?0 2.9 %
Xmax 7.0 mm
Xvar 8.5 mm
Mms 108 g
Bl 21.0 Txm
Le 1.3 mH
EBP 123 Hz
Mounting And Shipping Info
Overall diameter 389 mm (15.31 in)
Bolt circle diameter 374 mm (14.72 in)
Baffle cutout diameter 353.0 mm (13.9 in)
Depth 171 mm (6.73 in)
Flange and gasket thickness 11 mm (0.43 in)
Air volume occupied by driver 4.4 dm3 (0.15 ft3)
Net weight 3.2 kg (7.0 lb)
Shipping weight 3.7 kg (8.1 lb)
Shipping box 340x340x170 mm (13.4×13.4×6.7 in)
Service Kit
RCK15CL768
Marca: BYC
Codigo: 3009335
