Descripción
15″, 350/700w, 99,5dB, 40Hz, 40-2000Hz, 76mm, Copper, 4 ohm Specification
Nominal Diameter 380 (15) mm (in)
Nominal Impedance (1) 8 Ohm
Minimum Impedence 6.5 Ohm
Nominal Power Handling (2) 350 W Continuous
Power Handling (3) 700 W
Sensitivity (1W/1m) (4) 99.5 dB
Frequency Range 40 2000 Hz
Voice Coil Diameter 76 (3) mm (in)
Winding Material Copper
Former Material Glass Fibre
Winding Depth 16 (5/8) mm (in)
Magnetic Gap Depth 10 (0.4) mm (in)
Flux Density 1.15 T
Thiele & Small Parameters Fs 39 Hz Re 5.4 Ohm Qes 0.32 Qms 4.0 Qts 0.29 Vas 194 (6.5) dm3 (ft3) Sd 855 (132.5) cm2 (in2) Eta Zero 3.5 % Xmax +/- 4 mm Xvar +/- 4.5 mm Mms 88 g Bl 19.2 Txm Le 1.7 mH
Mounting and Shipping Info
Overall Diameter 392 mm (15.4 in)
Bolt Circle Diameter 374 mm (14.7 in)
Baffle Cutout Diameter 354 mm (13.9 in) Depth 171 mm (6.7 in)
Flange and Gasket Thickness 12.5 mm (0.5 in)
Net Weight 3.8 kg (8.4 lb)
Shipping Weight 5.5 kg (12.1 lb)
Shipping Box 450x450x200 mm (17.7×17.7×7.9 in)
Marca: BYC
Codigo: 3009336
