Descripción
12″,350/700w,98.5dB,48Hz,45-?3000Hz,76mm,Copper, 8 ohm
Specifications
Nominal diameter 320 mm (12.0 in)
Nominal impedance 8 O
Minimum impedance 6.5 O
Nominal power handling * 350 W
Continuous power handling * 700 W
Sensitivity (1W/1m) * 98.5 dB
Frequency range 45 3000 Hz
Voice coil diameter 76 mm (3.0 in)
Winding material Copper
Former material Glass Fibre
Winding depth 17 mm (0.67 in)
Magnetic gap depth 11 mm (0.43 in)
Flux density 1.05 T
Design
Surround shape Triple Roll
Cone shape Exponential
Magnet material Neodymium Inside Slug
Spider Single
Pole design Straight Pole
Woofer cone treatment WP Waterproof Front Side
Recommended enclosure 40.0 dm3 (1.41 ft3)
Recommended tuning 60 Hz
Parameters *
Fs 48 Hz
Re 5.2 O
Qes 0.22
Qms 4.8
Qts 0.21
Vas 59.0 dm3 (2.1 ft3)
Sd 522.0 cm2 (80.9 in2)
?0 2.9 %
Xmax 6.0 mm
Xvar 8.5 mm
Mms 70 g
Bl 22.4 Txm
Le 1.5 mH
EBP 218 Hz
Mounting And Shipping Info
Overall diameter 313 mm (12.32 in)
Bolt circle diameter 299 mm (11.77 in)
Baffle cutout diameter 282.0 mm (11.1 in)
Depth 142 mm (5.59 in)
Flange and gasket thickness 9 mm (0.35 in)
Air volume occupied by driver 2.3 dm3 (0.08 ft3)
Net weight 3.0 kg (6.6 lb)
Shipping weight 3.5 kg (7.7 lb)
Shipping box 340x340x170 mm (13.4×13.4×6.7 in)
Service Kit
RCK12CL768
Marca: BYC
Codigo: 3009328
