Descripción
1.4″,80/160w,107dB,1.0-?18kHz,65mm(2.5″),Aluminum, 8 ohm
Specifications *
Throat diameter 36 mm (1.4 in)
Nominal impedance 8 O
Minimum impedance 7.9 O
Nominal power handling * 80 W
Continuous power handling * 160 W
Sensitivity (1W/1m) * 107.0 dB
Frequency range 1 18 kHz
Recommended crossover * 1.2 kHz
Voice coil diameter 65 mm (2.5 in)
Winding material Aluminium
Inductance 0.15 mH
Diaphragm material Titanium
Flux density 1.8 T
Magnet material Neodymium Ring
Mounting And Shipping Info
Four M6 holes 90° on 102 mm (4 in) diameter
Overall diameter 115 mm (4.5 in)
Depth 52 mm (2.0 in)
Net weight 1.75 kg (3.85 lb)
Shipping units 1
Shipping weight 1.85 kg (4.0 lb)
Shipping box 135x135x55 mm (5.3×5.3×2.1 in)
Replacement Diaphragm
MMD6208
Modelo: DE620TN
Marca: BYC
Codigo: 3009358
