Descripción
1.4″,80/160w,108dB,1.0-?18kHz,65mm(2.5″),Aluminum, 8 ohm Specifications *
Throat diameter 36 mm (1.4 in)
Nominal impedance 8 O
Minimum impedance 7.6 O
Nominal power handling * 80 W
Continuous power handling * 160 W
Sensitivity (1W/1m) * 108.0 dB
Frequency range 1 – 18 kHz
Recommended crossover * 1.2 kHz
Voice coil diameter 65 mm (2.5 in)
Winding material Aluminium
Inductance 0.15 mH
Diaphragm material Titanium
Flux density 1.75 T
Magnet material Ferrite
Mounting And Shipping Info
Four M6 holes 90° on 102 mm (4 in) diameter
Overall diameter 156 mm (6.1 in)
Depth 65 mm (2.5 in)
Net weight 3.8 kg (8.4 lb)
Shipping units 2
Shipping weight 8.3 kg (18.3 lb)
Shipping box 210x210x190 mm (8.3×8.3×7.5 in)
Replacement Diaphragm
MMD6108
Modelo: DE610
Marca: BYC
Codigo: 3009356
