Descripción
1.4″,110/220w,108.5dB,500Hz-?18kHz,75mm(3.0″),Aluminum, 8, 16 ohm
Specifications *
Throat diameter 36 mm (1.4 in)
Nominal impedance 8 O
Minimum impedance 7.8 O
Nominal power handling * 110 W
Continuous power handling * 220 W
Sensitivity (1W/1m) * 108.5 dB
Frequency range 1 18 kHz
Recommended crossover * 1.2 kHz
Voice coil diameter 75 mm (3.0 in)
Winding material Aluminium
Inductance 0.14 mH
Diaphragm material Titanium
Flux density 2.05 T
Magnet material Neodymium Ring
Mounting And Shipping Info
Four M6 holes 90° on 102 mm (4 in) diameter
Overall diameter 131 mm (5.2 in)
Depth 65 mm (2.6 in)
Net weight 2.6 kg (5.7 lb)
Shipping units 4
Shipping weight 11.0 kg (24.2 lb)
Shipping box 300x160x180 mm (11.8×6.3×7.1 in)
Replacement Diaphragm
MMD900TN8
Modelo: DE900TN
Marca: BYC
Codigo: 3009359
