Descripción
1.4″,110/220w,106.5dB,500Hz-?18kHz,75mm(3.0″),Aluminum, 8 ohm
Specifications *
Throat diameter 36 mm (1.4 in)
Nominal impedance 8 O
Minimum impedance 8.5 O
Nominal power handling * 110 W
Continuous power handling * 220 W
Sensitivity (1W/1m) * 106.0 dB
Frequency range 500 18 kHz
Recommended crossover * 1.0 kHz
Voice coil diameter 75 mm (3.0 in)
Winding material Aluminium
Inductance 0.14 mH
Diaphragm material Titanium
Flux density 1.8 T
Magnet material Ferrite
Mounting And Shipping Info
Four M6 holes 90° on 102 mm (4 in) diameter
Overall diameter 170 mm (6.7 in)
Depth 64 mm (2.5 in)
Net weight 4.5 kg (9.9 lb)
Shipping units 2
Shipping weight 9.6 kg (21.2 lb)
Shipping box 210x210x190 mm (8.3×8.3×7.5 in)
Replacement Diaphragm
MMD3ATN8
Modelo: DE82TN
Marca: BYC
Codigo: 3009357
