Descripción
18 Sound 2″ 160W Neo
Throat Diameter 50 mm (2 in)
Rated Impedance 8 Ohm
D.C. Resistance 6,2 Ohm
Minimum Impedance 8 Ohm at 3500 Hz
Le (1kHz) 124 µH
AES Power 80 W above 1,2 kHz
Program power (8) 160 W above 1,2 kHz
Sensitivity (9) 110 dB
Frequency Range 500 Hz – 20 kHz
Recomm. Xover Frequency Above 800Hz (12 dB/oct slope)
Diaphragm material Aluminum – Polyethylene
Voice Coil Diameter 75 mm (3 in)
Voice Coil winding material Edge-wound aluminum
Magnet material Neodymium
Flux Density 1,9 T
Bl Factor 13,5 N/A
Polarity Positive voltage on the red terminal gives positive pressure in the throat
Mounting information
Overall diameter 132,5 mm (5,22 in)
N. of mounting holes and bolt 4 M6 holes 90° at Ø102 mm (4 in)
Bolt circle diameter 102mm (4 in)
Total depth 99 mm (3,9 in)
Net weight 3,6 kg (7,9 lb)
Shipping weight 4 kg (8,8 lb)
Packaging Dimensions 132x132x103 mm(5,2×5,2×4,1 in)
Modelo: ND2060A
Marca: 18SOUND
Codigo: 3009523
